Product details
| Model No | XPG PYLON 80PLUS Bronze 650W Power Supply |
| Part No | PYLON650B-BKCGB |
| Color | Black |
| Form Factor | Intel ATX 12V V2.4 (Timing complies with Intel ATX12V Specific guidelines to version 2.52) |
| Power | 650W |
| PFC | 0.99 |
| Input Voltage | 100-240V |
| Input Current | 750W：10A/5A 、650W：10A/5A 、550W：8A/4A 、450W：7A/3.5A |
| Input Frequency | 50Hz – 60Hz |
| Fan Size | 120mm |
| Fan Bearing | FDB (Fluid Dynamic Bearing)* |
| Fan Speed | 2,000 RPM |
| Efficiency | 80 PLUS BRONZE |
| MTBF | 100K Hours at 25℃ |
| Protections | OCP / OVP / UVP / OPP / SCP / OTP / NLO / SIP |
| Modularity | Standard |
| Connectors | ATX 24 Pin Connector : 1 EPS 8 (4+4) Pin Connector : 1 EPS 8 Pin Connector : 1 PCI-E 6+2 Pin Connector : 4 Molex 4 Pin Connector : 3 SATA Connector : 8 Floppy 4 Pin Connector : 1 |
| Dimensions | 140 x 150 x 86mm |
| Weight | Product：1.87kg (4.1lb) ±5% with Package：2.38kg (5.2lb) ±5% |
| Warranty | 1 Year ( As per Manufacturer Policy ) |
