Product details
| Model | 860 EVO SATA M.2 SSD 500GB |
| Part No | MZ-N6E500BW |
| Interface | SATA 6 Gb/s Interface |
| Read/Write Speeds | 550/520 MB/s |
| Series | SSD 860 EVO |
| Storage Capacity | 500 GB |
| NAND Type | Samsung V-NAND 3bit MLC |
| Cache Memory | Samsung 512 GB Low Power DDR4 SDRAM |
| Trim Support | Yes |
| AES Encryption
| AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
| Security | AES 256-bit Full Disk Encryption, TCG/Opal V2.0, Encrypted Drive (IEEE1667) |
| S.M.A.R.T. Support | Yes |
| GC (Garbage Collection) | Auto Garbage Collection Algorithm |
| Power Consumption (W) | Average: 2.2 W Maximum: 4.0 W (Burst mode) Actual power consumption may vary depending on system hardware & configuration |
| Reliability (MTBF) | 1.5 Million Hours Reliability (MTBF) |
| Operating Temperature | 0 – 70 ℃ Operating Temperature |
| Shock | 1,500G & 0.5ms (Half sine) |
| Form Factor | M.2 SATA |
| Dimensions | 3.15″ X 0.87 ” X 0.09″ |
| Weight | 0.082 Kg |
| Warranty | 1 Year ( As per Manufacturer Policy ) |
