ROG MAXIMUS Z690 EXTREME GLACIAL D5

ALL-ROUND PERFORMANCE

ROG Maximus Z690 Extreme Glacial is the pinnacle of liquid-cooled engineering. It features an eye-catching monolithic cooling system known simply as the EK UltraBlock, which can effortlessly chill the entire motherboard with a carefully engineered labyrinth of water channels, sensors, and heatsinks. The Z690 Extreme Glacial also builds upon knowledge gained from engineering the previous generation to ambitiously expand an already ample landscape of heatsinks and coolant circulation. Two additional M.2 slots now benefit from UltraBlock magic, and VRM cooling has been boosted even further to support the power stages that 12^th Gen or 13^th Gen Intel Core processors can take advantage of.

• ROG WATER-COOLING ZONE
  Dual water-temperature headers and a flow-rate header feed information straight into the AI Suite utility, allowing you to track coolant temperatures and the flow rate of the entire loop.
• Water pump+
  A dedicated header can supply over 3 amps to a high-performance PWM or DC water pumps.
• Water in/out
  A dedicated header enables monitoring of temperatures at the input/output points of any component.
• Water flow
  A dedicated header enables constant monitoring of flow rate throughout the entire loop.
• COOLER BY DESIGN
  ROG Maximus Z690 Extreme Glacial features comprehensive cooling options that are configurable via Fan Xpert 4 or the UEFI BIOS.
• ROG FAN CONTROLLER
  The ROG Fan Controller offers an additional six headers that can be controlled via FanXpert 4. The card features two temperature-sensor headers, along with two thermistors that can be attached to various components. There are also six ARGB headers to illuminate ARGB fans.
• TEAMED POWER ARCHITECTURE
  Modern CPU architectures up the ante for motherboard power design by transitioning from deep power saving modes to full load almost instantaneously. The latest ROG VRM architecture rises to the challenge by utilizing teamed power stages to rapidly swing current, while maintaining exemplary thermal.
• DDR MEMORY OPTIMIZATION WITH AEMP
  Comprehensive memory tuning options are the cornerstone of ROG motherboards. For DDR5, the Maximus Z690 lineup breaks performance limits by providing a stacked suite of overclocking parameters for not only high-speed kits, but even entry-level memory modules that have a locked power management IC (PMIC).
  A dedicated circuit on the motherboard safely circumvents DDR5 memory PMIC restrictions, allowing you to step past the default 1.1-volt limit and push frequency and timings to the max.
  Ordinarily, a restricted PMIC that has been unlocked requires the system to be fully power-cycled each time memory voltage is adjusted. ROG motherboards leverage onboard hardware and firmware to cleverly work around this irksome limitation, enabling voltage adjustments to be applied through the same soft system-reset process employed for previous generations of DDR memory.

PERSONALIZATION

• EK® ULTRABLOCK​
  The Ultrablock effectively cools the CPU, VRM, mid-board M.2 slot, and Z690 chipset, ensuring system stability even under sustained high load.​​
• M.2 HEATSINKS
  The M.2 heatsink keep the dual M.2 SSD at optimum operating temperature for consistent performance and reliability.​
• M.2 BACKPLATE​S
  Integrated M.2 backplates help ensure that high-performance drives deliver peak performance, even when airflow is restricted​
• LEVEL UP PERFORMANCE
  The dashboard-style control panel of AI Suite 3 lets you fine-tune almost every aspect of your ROG Maximus Z690 Extreme Glacial system with ease. Get the best balance between performance, cooling, stability, and efficiency via one simple and intuitive interface.
• ANIME MATRIX™ LED DISPLAY
  This innovative display features an RGB grid of mini LEDs that can be programmed to show off style with custom lighting designs, unique animations and live audio visualizations. Plus, distinctive soundwave lighting effects can even flash to the sound of a person’s voice.
• GROW YOUR GAMING WORLD WITH AURA SYNC
  Up your game with complementary Aura Sync enhanced aesthetics, featuring preset lighting effects that can be easily synchronized across compatible ROG graphics cards, monitors, mice and keyboards to give your setup a unified look.
• LIVEDASH OLED
  The ROG Maximus Z690 Extreme Glacial includes LiveDash, a built-in 2-inch OLED panel that shows useful information and features customizable graphics. During the power-on, self-test (POST) phase, the OLED shows key stats in simple language using traditional POST codes. In normal operation, the panel can be programmed to show CPU frequency, device temperatures, fan speeds or water-cooling information. You can also personalize the default OLED GIF with a preferred image or animation.
• SONIC STUDIO III
  Sonic Studio supports HRTF-based (head-related transfer function*) virtual surround for headsets, casting an immersive aural landscape that draws you deeper into the action. The intuitive Sonic Studio interface also offers a range of EQ options and one-click presets, allowing you to tailor acoustics to suit personal preferences or the characteristics of your headset.
• ARMOURY CRATE
  Armoury Crate is a software utility designed to give you centralized control of supported gaming products, making it easy to tune the look and feel of your system. From a single intuitive interface, Armoury Crate helps you customize RGB lighting and effects for compatible devices and synchronize them with Aura Sync to create a unified lighting scheme across your system. In addition, Armoury Crate’s Fan Xpert4 tool provides comprehensive control over fans, water pumps and all-in-one (AIO) coolers.
• GRAPHICS CARD HOLDER
  Featuring a magnetic base, adjustable slider and hinge, the ROG Graphics Card Holder banishes sag and provides support where it’s needed most.

CONNECTIVITY

• WIFI 6E
  Onboard WiFi 6E technology takes advantage of the newly available radio spectrum in the 6 GHz band, providing up to three times the bandwidth of the 5 GHz band and up to seven 160 MHz bands to deliver ultrafast wireless networking speeds along with improved capacity and better performance in dense wireless environments.
• MARVELL® AQTION 10 GBPS ETHERNET
  Designed to meet the demanding requirements of power users and content creators, 10 Gbps onboard Ethernet provides a new level of home networking. With up to 10 times the bandwidth of standard gigabit Ethernet, you’ll enjoy streaming uncompressed 4K UHD videos and system backups and file transfers that are faster than ever before.
• INTEL® 2.5 GB ETHERNET
  Onboard 2.5 Gb Ethernet gives your wired connection a boost, with up to a 2.5X improvement over standard Ethernet connections for faster file transfers, smoother lag-free gaming and high-res video streaming.
• USB 3.2 GEN 2X2 FRONT-PANEL CONNECTOR WITH QUICK CHARGE 4+
  Quick Charge 4+ technology can rapidly charge devices at up to 60W with a PCIe power supply cable plugged into the nearby 6-pin connector.
• TWO THUNDERBOLT 4 USB-C PORTS
  Each port delivers up to 40 Gbps of bidirectional bandwidth for the latest high-speed devices and drives. Thunderbolt 4 also supports up to two external 4K displays and extends PCIe bandwidth to up to 32 Gbps.
• PCIe 5.0-Ready
  ROG Maximus Z690 Extreme Glacial is equipped with a PCIe 5.0 slot ideal for video cards and two PCIe 5.0 slots designed for M.2 drives, putting it on the cutting edge of GPU and storage device technology.
• ROG DIMM.2
  The ROG DIMM.2 module is an innovative expansion card that allows two M.2 drives to be connected via a DDR4 interface. You can then add a metal heatsink, helping to control thermals for maximum performance while elevating aesthetics.
  *DIMM.2 accommodates M.2 drives up to 22110 (110 mm) in length.
